DS18 X2 Ultra Compact Full Range Class D 2-Channel Car Amplifier 1140 Watts Amazing power and an amazing small footprint is what the DS18 X2 amp is all about. This tiny amp packs a powerful punch all while fitting in the palm of your hand! It is a perfect selection for audiophiles cramming audio in tight spaces. For example, you can fit multiple X series amps in most motorcycle fairings powering an entire system all while safely tucked away. Small enough to fit in your hand but powerful enough to power four high powered speakers, this little powerhouse pumps out 140 watts RMS x 2CH at 4 ohms and 230 watts RMS x 2CH at 2 ohms which is enough to get super loud sound with great clarity. Highlights Huge power for such a small size giving it high versatility in applications in which it can be used. Fits in most tight spaces and a high power per size ratio. 2 and 4 ohms stable pumping out 140 watts RMS at 4 ohms per channel or 230 watts RMS at 2 ohms per channel. Easily adjustable filters making tuning for mids or tweeters easy. Great For Motorcycle Audio Pro Audio Car Audio Marine Audio Powersports Audio Jeep Audio Technical Details X2 Product Manual CLASS CLASS-D AMPLIFIER TYPE MICRO STEREO FULL RANGE AMP CHANNELS 2 TOTALWATTS (PEAK) 1140W RMS POWER @ 4 OHMS 140W x 2CH RMS POWER @ 2 OHMS 230W x 2CH RMS POWER @ 1 OHMS
- RMS POWER @ 4 OHMS BRIDGE 380W x 1CH FREQUECY RESPONSE 20Hz - 20KHz SIGNAL/NOISE RATIO >90 dB EFFICIENCY @ 4 OHMS >80% DAMPING FACTOR >201 THD % <0.2% LOW LEVEL INPUT RANGE 0.2-5V SELECTABLE X-OVER LPF/FLAT/HPF X-OVER FILTER RANGE 40Hz - 400Hz BASS BOOST RANGE
- BASS BOOST FREQUENCY
- INFRASONIC FILTER
- PHASE SELECTOR
- MINIMUM IMPENDANCE 2 OHMS LED INDICATOR POWER/PROTECTION POWER INPUT SIZE 12GA FUSE RATING 40A REMOTE LEVEL CONTROL
- THERMAL PROTECTION YES OVER-LOAD PROTECTION YES DC OUTPUT PROTECTION YES SHORT CIRCUIT OUTPUT PROTECTIONVOLTAGE INPUT PROTECTION YES VOLTAGE INPUT PROTECTION YES DIMENSIONS LxWxH (INCHES) 5.54 x 3.24 x 1.37" HEATSINK LENGTH 4.75" COMPACT SIZE TO EASY INSTALLATION FOR ANY APLICATIONS YES STABLE/RELIABLE FOUR LAYERS TRACES PCB DESIGN YES SURFACE MOUNT COMPONENT TECHNOLOGY YES AUDIO PRECISION QUALITY CONTROL VERIFICATION YES CONFIGURATION 2CH/4CH INPUT SELECTOR NO
